Nvidia GeForce GTX 745
Maxwell
Architecture
Entry-level
Product Tier
384
Shader Cores
16
ROPs
24
TMUs
No RT
Ray Tracing
4 GB
Memory
GDDR5
Memory Type
28.80 GB/s
Bandwidth
55 W
TDP
| GPU Snapshot | |||
| Release date: | Feb 18, 2014 | Type: | Desktop |
| Architecture: | Maxwell | Generation: | GTX 700 series |
| Product Tier: | Entry-level | VRAM Capacity: | 4 GB |
| Total Board Power: | 55 W | ||
| Core Configuration | |||
| Shader Cores: | 384 | TMUs: | 24 |
| ROPs: | 16 | L2 Cache: | 2 MB |
| Memory | |||
| VRAM Capacity: | 4 GB | Memory Type: | GDDR5 |
| Memory Speed: | 1.8 Gbps | Memory Bus: | 128-bit |
| Bandwidth: | 28.8 TB/s | ||
| Graphics Processing | |||
| Base Clock: | 1.03 GHz | FP32 Throughput: | 0.79 TFLOPs |
| Ray Tracing: | No | Process Size: | 28nm |
| Process Name: | TSMC 28nm | Die Size: | 148 mm² |
| Power & Connectivity | |||
| Total Board Power: | 55 W | Power Connectors: | None |
| Bus Interface: | PCIe 3.0 x16 | HDMI Support: | HDMI 1.4a |
| DSC: | No | Max Displays: | 4 |
| Media & Software Support | |||
| DirectX Support: | 12 | Shader Model: | 6.7 |
| Vulkan Version: | 1.4 | OpenGL Version: | 4.6 |
