One of the most obvious impacts of the Covid-19 pandemic is how reliant we have all become on connectivity, particularly wireless connectivity. For most of us, the combination of a fast broadband connection along with a solid Wi-Fi wireless network inside our home has literally made the difference between being able to work, attend classes, and enjoy entertainment on a consistent, reliable basis or not being able to do so.
As a result, there’s significantly more attention being placed on connectivity overall these days, within all of our different devices. Of course, it doesn’t hurt that we’re also at the dawn of a new era of wireless connectivity, thanks to the recent launch of 5G networks and the growing availability of lower-cost 5G-capable devices. But, while 5G may currently be getting the lion’s share of attention, there have been some tremendously important developments happening in the world of Wi-Fi as well.
"Wi-Fi 6E connection speeds could prove to be significantly faster than even the best that 5G has to offer"
Just six weeks ago, the FCC gave official approval for Wi-Fi to extend its reach to an enormous swath of new radio spectrum in the 6 GHz band here in the US. Specifically, the new Wi-Fi 6E standard will have access to 1.2 GHz, or 1,200 MHz of radio spectrum, ranging from 5.9 GHz to 7.1 GHz (and incorporating all the 6 GHz frequencies in between, hence the 6 GHz references). Just to put that in perspective, even the widest connections for millimeter wave 5G—the fastest kind of 5G connection available—are limited to 800 MHz. In other words, the new Wi-Fi connections have access to nearly 1.5 times the amount of frequencies to transmit on as the fastest 5G connections.
Theoretically, that means that Wi-Fi 6E connection speeds could prove to be significantly faster than even the best that 5G has to offer. Plus, because of the basic laws of physics and signal propagation, Wi-Fi 6E coverage can actually be wider than millimeter wave 5G. To be fair, total coverage is very dependent on the amount of power used for transmission—cellular transmission levels are typically several times stronger than Wi-Fi—but in environments like office buildings, conference centers, as well as in our homes, it’s not unreasonable to expect that Wi-Fi 6E will be faster than 5G, just as current 5 GHz Wi-Fi (802.11a and its variants) are typically faster than 4G LTE signals.
One important clarification is that all of these benefits only extend to Wi-Fi 6E—not Wi-Fi 6, which is also relatively new. For Wi-Fi 6, there are a number of improvements in the way signals are encoded and transmitted, all of which should decrease the congestion and reduce the power requirements for using Wi-Fi. However, all those improvements still use the traditional 2.4 and 5 GHz frequency bands that Wi-Fi has used for the last 20 years. The critical new addition for Wi-Fi 6E is the 6 GHz frequency band.
To make sense of all this, you have to understand at least a little bit about radio frequency spectrum (whether you want to or not!). The bottom line is, the higher the frequency, the shorter the distance a wireless signal can travel and the lower the frequency, the farther it can travel. The analogy I like to use is to think of hearing a music concert from a far-away stadium. If you’re driving by a concert venue while a band is playing, you typically can hear a wide range of frequencies and can better make out what’s being played. The farther away you are, however, the more that the higher frequencies are harder to hear—all that’s left is the low-frequency rumble of bass frequencies, making it difficult to tell what song is being played. All radio frequency signals, including both cellular and Wi-Fi, follow these basic rules of frequency and distance.
There is a critically important twist for data transmission, however, and that has to do with availability and width of channels for transmitting (and receiving) signals. The basic rule of thumb is the lower the frequency, the smaller the channel width and the higher the frequency, the wider the channel width. Data throughput and overall wireless connection speed is determined by the width of these channels. For 4G and what’s called low-band 5G (such as with T-Mobile’s 600 MHz 5G network), those channels can be as small as 5 MHz wide or up to 20 MHz. The mmWave frequencies for 5G, on the other hand, are 100 MHz wide and, in theory up to eight of them are available for a total of 800 MHz of bandwidth.
The beauty of Wi-Fi 6E is that it supports up to 7 channels of 160 MHz, or a total of 1,120 MHz of bandwidth. (As a point of comparison, 5 GHz Wi-Fi supports a maximum of two 160 MHz channels and 500 MHz overall, while 2.4 GHz Wi-Fi only supports a maximum of three 20 MHz channels and 70 MHz overall.) In addition, Wi-Fi 6E has these wide channels at a significantly lower frequency than used for millimeter wave (typically 24 GHz and up, although most US carriers are using 39 GHz), which explains why Wi-Fi 6E can have broader coverage than mmWave. Finally, because 6 GHz spectrum will be unoccupied by other devices, the real-world speed should be even better. The lack of other traffic will enable much lower latency, or lag, times for devices on Wi-Fi 6E networks.
"To take advantage of Wi-Fi 6E, you need to have both routers and devices that support that standard"
Of course, to take advantage of Wi-Fi 6E, you need to have both routers and devices that support that standard. To do that, you need to use chips that also support the standard (as well as live in a country that supports the full frequency range—right now the US is leading the way and the only country to support the full 1.2 GHz of new spectrum). Broadcom and Intel have both announced support for Wi-Fi 6E, but the only company currently shipping chips for both types of devices is Qualcomm. For client devices like smartphones, PCs and others, the company offers the FastConnect 6700 and 6900, while for routers, the company has a new line of tri-band (that is, supporting 2.4 GHz, 5 GHz and 6 GHz) Networking Pro Series chips, including the Networking Pro 610, 810, 1210 and 1610, which support 6, 8, 12, and 16 streams, respectively, of Wi-Fi 6E connectivity.
In addition, the new Networking Pro line supports what the company calls Qualcomm Max User Architecture and Multi-User Traffic Management, which enable up to 2,000 simultaneous client connections, thanks to advanced OFDMA (Orthogonal Frequency-Division Multiple Access) and 8-user MU-MIMO (Multi User—Multiple Input, Multiple Output) per channel. The new router-focused Networking Pro chips also support SON (Self-Organizing Networks), which makes them well suited for future versions of Wi-Fi mesh routers.
"The good news for those of us in the US is that we’re about to enjoy a significantly improved range of wireless networking options, thanks to both of these recent Wi-Fi 6E enhancements"
In a way, the benefits of Wi-Fi 6E offer an interesting challenge for Qualcomm and other companies that make both 5G cellular and Wi-Fi-focused chips and devices. For certain applications—notably public venues, certain office environments, etc.—the two technologies are likely to compete directly with one another, in which case the core component companies will essentially have to sell against themselves. Because of the increasingly complex range of wireless network architectures, different security requirements, business models and more, however, the likely truth is that both technologies will co-exist for some time to come. As a result, it makes better business sense to have offerings that support both than to simply pick a side.
The good news for those of us in the US is that we’re about to enjoy a significantly improved range of wireless networking options, thanks to both of these recent Wi-Fi 6E enhancements, as well as the forthcoming auctions for mid-band (3.5 GHz) 5G spectrum. Despite the many other challenges we face, it’s looking to be a good year for wireless.
Bob O’Donnell is the founder and chief analyst of TECHnalysis Research, LLC a technology consulting and market research firm. You can follow him on Twitter @bobodtech. This article was originally published on Tech.pinions.
